Suspension leaf spring

LEAF SPRING AND SHOCK ABSORBERS

Code

Action Duration

1 481011 LEAF SPRING (ONE SIDE) - RE-

PLACEMENT

2 481012 LEAF SPRING (ONE SIDE) - SERV-

ICE

3 481021 LEAF SPRING (BOTH SIDES) - RE-

PLACEMENT

4 481022 LEAF SPRING (BOTH SIDES) -

SERVICE

5 481201 LEAF SPRING SUPPORTS AND/

OR BUSHING (ONE SIDE) - RE-

PLACEMENT

6 481301 SHOCK ABSORBER (ONE SIDE) -

REPLACEMENT

7 481302 SHOCK ABSORBER (BOTH

SIDES) - REPLACEMENT

PORTER 1.3 16V Time-sheet

TS - 819
