Removal
Starting operations
1. Disconnect the battery negative cable.
2. Remove the steering wheel (steering section
reference).
3. Pull out the panel of the instrument panel.
4. Remove the instrument panel and the warning
lights by taking out the five screws.
5. Disconnect the speedometer cable and electric
connections.
6. Remove the diffuser hand grip by taking out the
relevant screw.
7. Take out the heating adjustment lever.
8. Central upholstery panel removal.
- Remove the two screws.
- Remove the clip.
- Take out the panel.
9. Remove the heating adjustment unit.
Removing the upper panel of the instrument
panel and the glove compartment
1. Press firmly the left end section A as shown in
the figure, operating in the direction indicated by
the arrow. Then, open the section joint B. Fit a
screwdriver wrapped with protective tape in order
to disconnect section B.
2. Insert a screwdriver in section C so as to detach
it.
Chassis PORTER 1.3 16V
CH - 780
