AIR CONDITIONING REMOTE CONTROLS
13 - Cab electric fan control remote control (first
speed). 20 - Ground with eyelet terminal. 21 -
Electric fan control switch remote control 22 - 30A
Fuse 25 - Compressor electromagnetic coupling
control remote control 26 - 7.5A Fuse
Electrical controls
Multifunction switch lever
Check
1. Make sure that turn indicators, low-beam/high-beam lights, hazard indicator and windscreen wiper
switches work properly.
2. Disconnect the multifunction switch lever connector. Make sure there is continuity between the rel-
evant terminals according to the continuity tables shown in the following diagram.
PORTER 1.3 16V Electrical system
ES - 85
