Then the first individual locks the
bleeding cap and the second one re-
leases the brake pedal.
•
Repeat the operations described in
previous points until there are no more
air bubbles in the fluid container.
Brake fluid leakage check
Push the brake pedal and check there are no fluid leaks in all the pipe sections.
Front disc brake pad
Removal
Removal
Remove the parts, following the numerical order shown in the figure below.
KEY:
1. Screw
2. Disc brake calliper unit
3. Clip
4. Pad pin
5. Pad unit and thickness
Braking system PORTER 1.3 16V
BS - 622
