1. Remove the probe from the cylinder head.
2. Measure the resistance value between the terminal and ground at the following temperatures:
Temperature (°C) Resistance value ()
50 26.0
115 26.0
Controllo impianto di accensione
Ignition check
Spark plug
1. Connect the stroboscopic light terminal to the
ignition coil cable harness.
KEY:
A. Probe
B. Ignition coil
2. Check that the stroboscopic light flashes while
the engine in being run with the starter motor.
3.If it does not flash, carry out the following checks.
Remove the fuel pump relay from the relay hous-
ing.
4. Disconnect the ignition coil connector.
5. Remove the ignition coil and the spark plug.
6. Connect a spark plug and a connector to the
ignition coil.
- TESTER DS. 21. CAN BE USED
PORTER 1.3 16V Electrical system
ES - 163
