Handbrake
Reserve travel
Apply 196 N (20 kgf) of force, slowly pull the hand-
brake lever upwards and count the notches.
Characteristic
Number of notches:
6 ÷ 10
Parking brake cable
Removal
Operation before removal(pickup model)
•
Remove the engine inspection compartment cover.
•
Lift the front left seat.
•
Remove the rear brake drum. Disconnect the parking brake cable from the rear brake
Removal (Pickup)
Remove the parts, following the numerical order shown in the figure.
KEY:
1. Parking brake cable right guide
2. Parking brake cable left guide
PORTER 1.3 16V Braking system
BS - 637
