4 Device control (DCTRL)
4.1 Device commands (C00002/x)
104
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.1.2 Load all parameter sets
The C00002/6 = "1: On / start" device command reloads all parameter settings from the memory
module to the inverter.
• Can only be executed if the controller is inhibited; otherwise, the feedback C00002/6
="6: No
access - controller inhibit" will be returned.
• All parameter changes made since the last saving of the parameter set will get lost!
• This device command has an effect on the settings of the parameters of the operating system,
application and module.
 How to load the parameter settings from the memory module:
1. If the inverter is enabled, it must be inhibited, e.g. by executing the "Enable/Inhibit
inverter" device command "(C00002/16
="0:Off/ready").
2. Execute the "Load all parameter sets" device command:
C00002/6
="1:On / start"
The loading process may take a couple of seconds. After the device command has been
called, C00002/6
returns dynamic status information ("Work in progress 20 %"  "Work in
progress 40 %"  "Work in progress 60 %", etc.).
Notes on execution time
The execution time of this device command depends on the communication module used. If - in
addition to the device-internal time monitoring - a monitoring of the execution time is to be
implemented for this device command in a higher-level control, the monitoring time has to be 2 ...
3 times higher than the times specified in the following table:
 Note!
The inverter is currently provided with one data record for all parameters, i.e. every
parameter has a value. Several data records per inverter are in preparation.
From version 04.00.00 onwards, the basic function Parameter change-over
provides a
change-over between four sets with different parameter values for up to 32 freely
selectable parameters.
( 789)
Communication module used Typical execution time
StateLine C HighLine C TopLine C
Without communication module 3.5 s
3.5 s 3.5 s
PROFIBUS® or INTERBUS 3.5 s
3.5 s 3.5 s
EtherCAT®, PROFINET® or EtherNet/IP™ 4.0 s
3.5 s 4.0 s
Ethernet POWERLINK 15.0 s
15.0 s 15.0 s
