9 Diagnostics & error management
9.2 LED status displays
624
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.2 LED status displays
Related topics:
Device control (DCTRL)
( 98)
Device state machine and device states
( 112)
System bus "CAN on board"
( 700)
Information on some of the operating states can be quickly obtained via the
LED display on the front of the inverter.
Labelling Colour Description
CAN-RUN green CAN bus ok LED status displays for
the system bus ( 706)
CAN-ERR red CAN bus error
DRV-RDY green Standard device ready for operation LED s tatus di splay s of the
device status ( 625)
DRV-ERR red Warning/trouble/fault
CAN-RUN
CAN-ERR
DRV-RDY
DRV-ERR

Lenze 8400 Specifications

General

Category	DC Drives
Series	8400
Protection class	IP20
Control Type	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Input Voltage	AC 230/400/480 V
