Lenze 8400 User Manual

17 Function library
17.1 Function blocks | L_And5_2
1259
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.1.13 L_And5_2
This FB implements AND operations for input signals.
Inputs
Outputs
Function
[17-5] Truth table of the FB L_And5_2
Designator
Data type
Information/possible settings
bIn1
...
bIn5
BOOL
Input signal
Designator
Data type
Value/meaning
bOut
BOOL
Output signal
Inputs Output
bIn5 bIn4 bIn3 bIn2 bIn1 bOut
FALSE FALSE FALSE FALSE FALSE FALSE
FALSE FALSE FALSE FALSE TRUE
FALSE FALSE FALSE TRUE FALSE
FALSE FALSE FALSE TRUE TRUE
FALSE FALSE TRUE FALSE FALSE
...
TRUE TRUE TRUE FALSE TRUE
TRUE TRUE TRUE TRUE FALSE
TRUE TRUE TRUE TRUE TRUE TRUE
/B$QGB
E,Q E2XW
E,Q
E,Q

E,Q
E,Q
