15 Parameter reference
15.7 Table of attributes
1174
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
15.7 Table of attributes
The table of attributes contains information that is required for communication with the inverter
via parameters.
How to read the table of attributes:
Column Meaning Entry
Code Parameter name Cxxxxx
Name Parameter short text (display text) Text
Type Parameter type Selection list Value from selection list
Bit coded Bit coded value
Linear value Value with setting range
String String
Index dec Index under which the parameter is addressed.
The subindex for array variables corresponds to the
Lenze subcode number.
24575 - Lenze code number Is only required for access via a bus
system.
hex 5FFF
h
- Lenze code number
Data DS Data structure E Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type INTEGER_16 2 bytes with sign
INTEGER_32 4 bytes with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 bytes without sign
UNSIGNED_32 4 bytes without sign
VISIBLE_STRING [xx] ASCII string (with character length xx)
Factor Factor for data transmission via a bus system,
depending on the number of decimal positions
Factor 1 ≡ No decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
10000 ≡ 4 decimal positions
CINH Writing is only possible if the controller is inhibited CINH
Code Name Type Index Data
dec hex DS DA Data type Factor CINH
C00001
Keypad UserLevel Selection list 24574 5FFE A 1 UNSIGNED_8 1
C00002
Device commands Selection list 24573 5FFD A 33 UNSIGNED_8 1
C00003
Status of the last device command Selection list 24572 5FFC E 1 UNSIGNED_8 1
C00005 Application Selection list 24570 5FFA E 1 UNSIGNED_16 1
C00006
Motor control Selection list 24569 5FF9 E 1 UNSIGNED_8 1
C00007
Control mode Selection list 24568 5FF8 E 1 UNSIGNED_16 1
C00008
Original application|control source Selection list 24567 5FF7 E 1 UNSIGNED_16 1
C00010 AIN1: Characteristic Linear value 24565 5FF5 A 8 INTEGER_16 100
C00011
Appl.: Reference speed Linear value 24564 5FF4 E 1 UNSIGNED_16 1
C00012
Accel. time - main setpoint Linear value 24563 5FF3 E 1 UNSIGNED_32 1000
C00013
Decel. time - main setpoint Linear value 24562 5FF2 E 1 UNSIGNED_32 1000
C00015
VFC: V/f base frequency Linear value 24560 5FF0 E 1 UNSIGNED_16 10
C00016
VFC: Vmin boost Linear value 24559 5FEF E 1 UNSIGNED_16 100
C00018 Switching frequency Selection list 24557 5FED E 1 UNSIGNED_8 1
C00019
Auto-DCB: Threshold Linear value 24556 5FEC E 1 UNSIGNED_16 1
C00020
AIN2: Characteristic Linear value 24555 5FEB A 8 INTEGER_16 100
C00021 Slip comp. Linear value 24554 5FEA E 1 INTEGER_16 100
C00022
Imax in motor mode Linear value 24553 5FE9 E 1 UNSIGNED_16 100
Greyed out = display parameter (read only access)
