17 Function library
17.2 System blocks | LS_DisFree_p
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.2.11 LS_DisFree_p
This system block displays 8 arbitrary position signals of the application on display codes.
Inputs
Parameters
17.2.12 LS_DriveInterface
Interface to internal device control.
Designator
Data type
Information/possible settings
dnDis1_p ... dnDis8_p
DINT
From version 11.00.00 onwards:
dnC483_1_p ... dnC483_8_p
Inputs for arbitrary position signals of the application
Note: From version 11.00.00 the inputs are named according to the display
parameter for an easier allocation.
Parameters Possible settings Info
C00483/1...8
-2147483647 Incr. 2147483647 Display of the position signals which
are applied at the
dnDis1_p ... dnDis8_p inputs
GQ'LVBS
GQ'LVBS
GQ'LVBS
GQ'LVBS
GQ'LVBS
GQ'LVBS
GQ'LVBS
GQ'LVBS
&
&
&
&
&
&
&
&
/6B'LV)UHHBS
 For a detailed description see main chapter "Device control (DCTRL)":
Internal interfaces | "LS_DriveInterface" system block
( 126)
