15 Parameter reference 15.3 Overview of all parameters with power-related Lenze setting Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1157 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
15.3 Overview of all parameters with power-related Lenze setting
Mains voltage / device power
1 * 230 V 3 * 400 V
Parameters Name Unit 0.25 kW 0.37 kW 0.55 kW 0.75 kW 1.1 kW 1.5 kW 2.2 kW 0.37 kW 0.55 kW 0.75 kW 1.1 kW 1.5 kW
C00016
VFC: Vmin boost % 5.51 4.32 4.02 3.79 4.32 2.93 2.25 4.32 4.02 3.79 4.32 2.93
C00021
Slip comp. % 8.6766.3367.337 4 66.3367.337
C00022
Imax in motor mode A 2.97 4.2 5.25 7 9.62 12.25 16.62 2.27 3.15 4.2 5.6 6.82
C00070/1
SLVC: Vp speed controller 7.62 15.76 12.59 18.9 12.52 12.45 15.76 15.76 12.59 18.9 12.52 12.45
C00070/2
SC: Vp speed controller 4.35 9.01 7.19 10.8 7.15 7.11 9.01 9.01 7.19 10.8 7.15 7.11
C00070/3
SLPSM: Vp speed controller 1.09 2.25 1.79 2.7 1.79 1.78 2.25 2.25 1.8 2.7 1.79 1.78
C00073/1
VFC: Vp Imax controller 0.460.320.330.270.330.32 0.2 0.28 0.3 0.270.330.32
C00074/1
VFC: Ti Imax controller ms 656565656565656565656565
C00075
Vp current controller V/A 41.88 34.59 23.43 14.97 9.53 7.23 4.73 103.76 70.29 44.9 28.54 21.7
C00076
Ti current controller ms 1.99 2.42 2.6 2.39 1.97 2.83 3.55 2.42 2.6 2.39 1.97 2.83
C00077
SC: Vp field controller 1.682.833.324.923.964.715.432.833.324.923.964.71
C00078
SC: Tn field controller ms 33.6 56.6 66.3 98.3 79.1 94.2 108.6 56.6 66.3 98.3 79.1 94.2
C00081
Rated motor power kW 0.25 0.37 0.55 0.75 1.1 1.5 2.2 0.37 0.55 0.75 1.1 1.5
C00082
Motor rotor resistance mOhm 11460 5480 3860 2820 2060 1438 740 16442 11580 8454 6150 4320
C00084
Motor stator resistance mOhm 10533 7133 4500 3127 2420 1277 667 21400 13500 9380 7260 3830
C00085
Motor stator leakage inductance mH 20.94 17.29 11.72 7.48 4.77 3.62 2.37 51.88 35.15 22.45 14.27 10.85
C00087
Rated motor speed rpm 1370 1410 1405 1410 1390 1395 1440 1410 1405 1410 1390 1395
C00088
Rated motor current A 1.4 1.6 2.4 3.3 4.8 6.3 9.2 0.95 1.4 1.9 2.8 3.6
C00090
Rated motor voltage V 230 230 230 230 230 230 230 400 400 400 400 400
C00091
Motor cosine phi 0.63 0.72 0.72 0.8 0.8 0.79 0.71 0.77 0.77 0.8 0.8 0.79
C00092
Motor magnetising inductance mH 333.3 386.7 286.7 300 186.7 116.7 70 1160 860 900 560 350
C00093
Power section ID 2512 3712 5512 7512 1122 1522 2222 3714 5514 7514 1124 1524
C00095
Motor magnetising current A 0.94 0.88 1.35 1.28 2.25 3.46 5.54 0.51 0.78 0.74 1.3 2
C00098
Rated device current A 1.7 2.4 3 4 5.5 7 9.5 1.3 1.8 2.4 3.2 3.9
C00129
Brake resistance value Ohm 180 180 100 100 33 33 33 390 390 390 180 180
C00130
Rated brake resistor power W 50 50 100 100 200 200 300 100 100 100 200 200
C00131
Rated heat amount of brake resist. kWs 7.5 7.5 15 15 30 30 45 15 15 15 30 30
C00497
Filter time constant ms 111111111111
C00916
Motor cable cross-section mm^211111.51.51.51111.51.5
C00966
VFC: Time const. slip comp. ms 100 100 100 100 100 100 100 100 100 109 100 100
C00982 VFC-ECO: Voltage reduction ramp s 0.10.20.20.30.30.30.30.20.20.30.30.3
C00987
Inverter motor brake: nAdd rpm 260 180 190 180 220 210 120 180 190 180 220 210
C00993
Flying restart: Integration time ms 300 300 300 300 300 300 300 300 300 300 300 300
