15 Parameter reference
15.4 Selection list - analog signals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
15.4 Selection list - analog signals
This selection list is relevant for the following
configuration parameters:
Parameters
C00410 L_SignalMonitor_a: Signal sources
C00620
System connection list: 16-bit
C00700
LA_NCtrl: Analog connection list
C00710
LA_TabPos: Analog connection list
C00760
LA_SwitchPos: Analog connection list
Selection list - analog signals
0 Not connected
1000 LA_NCtrl: wDriveControlStatus
1001 LA_NCtrl: wStateDetermFailNoLow
1002 LA_NCtrl: nMotorCurrent_a
1003 LA_NCtrl: nMotorSpeedAct_a
1006 LA_NCtrl: nGPAnalogSwitchOut_a
1007 LA_NCtrl: nGPArithmetikOut_a
1008 LA_NCtrl: nGPMulDivOut_a
1009 LA_NCtrl: nGPSignalOut1_a
1010 LA_NCtrl: nGPSignalOut2_a
1011 LA_NCtrl: nGPSignalOut3_a
1012 LA_NCtrl: nGPSignalOut4_a
1013 LA_NCtrl: nMotorTorqueAct_a
1014 LA_NCtrl: nDCVoltage_a
1015 LA_NCtrl: nMotorVoltage_a
1016 LA_NCtrl: nMotorSpeedSet_a
1017 LA_NCtrl: wStateDetermFailNoHigh
1023 LA_NCtrl: wFreeOut1
1024 LA_NCtrl: wFreeOut2
1025 LA_NCtrl: wFreeOut3
1026 LA_NCtrl: wFreeOut4
1100 LA_TabPos: wDriveControlStatus
1101 LA_TabPos: wStateDetermFailNoLow
1102 LA_TabPos: wStateDetermFailNoHigh
1103 LA_TabPos: nMotorCurrent_a
1104 LA_TabPos: nMotorSpeedSet_a
1105 LA_TabPos: nMotorSpeedAct_a
1106 LA_TabPos: nMotorTorqueAct_a
1107 LA_TabPos: nDCVoltage_a
1108 LA_TabPos: nMotorVoltage_a
1109 LA_TabPos: wMckState1
1110 LA_TabPos: wMckState2
1111 LA_TabPos: wMckActOperationMode
1112 LA_TabPos: wActProfileNo
1113 LA_TabPos: wActPosMode
1114 LA_TabPos: nGPAnalogSwitchOut_a
1115 LA_TabPos: nGPArithmetikOut_a
1116 LA_TabPos: nGPMulDivOut_a
1117 LA_TabPos: nGPSignalOut1_a
1118 LA_TabPos: nGPSignalOut2_a
1119 LA_TabPos: nGPSignalOut3_a
1120 LA_TabPos: nGPSignalOut4_a
1121 LA_TabPos: wGPCounter1Out
1122 LA_TabPos: wFreeOut1
1123 LA_TabPos: wFreeOut2
1124 LA_TabPos: wFreeOut3
1125 LA_TabPos: wFreeOut4
1126 LA_TabPos_In: nPosCtrlOutLimit_a
1127 LA_TabPos_In: nPosCtrlPAdapt_a
1128 LA_TabPos: wPosOutUnitsLW
1129 LA_TabPos: wPosOutUnitsHW
1200 LA_SwitchPos: wDriveControlStatus
1201 LA_SwitchPos: wStateDetermFailNoLow
1202 LA_SwitchPos: wStateDetermFailNoHigh
1203 LA_SwitchPos: nMotorCurrent_a
1204 LA_SwitchPos: nMotorSpeedSet_a
1205 LA_SwitchPos: nMotorSpeedAct_a
1206 LA_SwitchPos: nMotorTorqueAct_a
1207 LA_SwitchPos: nDCVoltage_a
1208 LA_SwitchPos: nMotorVoltage_a
1209 LA_SwitchPos: nGPAnalogSwitchOut_a
1210 LA_SwitchPos: nGPArithmetikOut_a
1211 LA_SwitchPos: nGPMulDivOut_a
1212 LA_SwitchPos: nGPSignalOut1_a
1213 LA_SwitchPos: nGPSignalOut2_a
1214 LA_SwitchPos: nGPSignalOut3_a
1215 LA_SwitchPos: nGPSignalOut4_a
1221 LA_SwitchPos: wFreeOut1
1222 LA_SwitchPos: wFreeOut2
1223 LA_SwitchPos: wFreeOut3
1224 LA_SwitchPos: wFreeOut4
16000 LS_AnalogInput: nIn1_a
16001 LS_AnalogInput: nIn2_a
16002 LP_CanIn1: wCtrl
16003 LP_CanIn1: wIn2
16004 LP_CanIn1: wIn3
16005 LP_CanIn1: wIn4
16006 LP_CanIn2: wIn1
16007 LP_CanIn2: wIn2
16008 LP_CanIn2: wIn3
16009 LP_CanIn2: wIn4
16010 LP_CanIn3: wIn1
16011 LP_CanIn3: wIn2
16012 LP_CanIn3: wIn3
16013 LP_CanIn3: wIn4
16014 LS_DigitalInput: wCountIn1_LW
16015 LS_DigitalInput: wCountIn1_HW
16016 LS_DigitalInput: nFreqIn12_a
16017 LS_DigitalInput: nFreqIn12_v
16018 LS_DigitalInput: wCountIn6_LW
Selection list - analog signals
