3 Commissioning
3.7 Commissioning of the "Actuating drive speed" technology application
60
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.7.2 Creating an »Engineer« project & going online
The following steps serve to describe a general method for creating a project with the Select
component from catalogue option. For this purpose, individual components ( inverter, motor, etc.)
are selected from selection lists.
1. Start »Engineer«.
2. Create a new project with the Start-up wizard and the Select component from catalogue option:
•In the Component step, select the 8400 HighLine inverter.
•In the Device modules step, select the available communication module.
•In the Application step, select the "Actuating drive speed" application. (The application can
also be selected any time afterwards via the Application parameter tab or C00005
.)
• Select the other components (motor/gearbox) to be added to the project in the Other
components dialog step.
3. Going online.
After a connection to the inverter has been established, the following status is displayed in the
Status line:
4. Download parameter set.
This command serves to overwrite the current parameter settings in the inverter by parameter
settings of the »Engineer« project.
You can find detailed information on the general use of the »Engineer« in the online help
which you can call with [F1].
• In the "Working with projects" chapter, all options of the start-up wizard are described
to create a new »Engineer« project.
