5 Motor control (MCTRL)
5.16 Internal status signals | System block "LS_DeviceMonitor"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.16 Internal status signals | System block "LS_DeviceMonitor"
The LS_DeviceMonitor system block provides the status signals of the motor control in the function
block editor.
[5-37] LS_DeviceMonitor system block (excerpt)
Outputs
 Note!
The LS_DeviceMonitor system block can only be inserted on the application level.
If status signals of the motor control function are to be output via digital outputs or
example, you can use the free bFreeOut1 ... bFreeOut8 outputs of the application block
to transfer the desired status signals from the application level to the I/O level. On the
I/O level, you can then establish the logical link to the digital output terminals.
/6B'HYLFH0RQLWRU
E0FWUO,PS$FWLYH
E0FWUO&ODPS$FWLYH
E0FWUO0RWRU3KDVH)DXOW
E0FWUO(QFRGHU&RP)DXOW
E0FWUO1PD[
E0FWUO7RUTXH0D[
E0FWUO)&KRS5HGXFHG
E0FWUO,[W2YHUORDG
Q0FWUO,[W5DWHBD
'HYLFH
PRQLWRU
Designator
Data type
Value/meaning
bMctrlImpActive
BOOL
TRUE Pulse inhibit is active
bMctrlClampActive
BOOL
TRUE Clamp current limitation is active
bMctrlMotorPhaseFault
BOOL
Status of the Motor phase failure monitoring
TRUE Motor phase fault has been detected
bMctrlEncoderComFault
BOOL
TRUE Encoder error has been detected
bMctrlNmax
BOOL
TRUE Max. speed limitation is active
bMctrlTorqueMax
BOOL
Status of the Maximum torque monitoring
TRUE Max. torque limitation is active
bMctrlFChopReduced
BOOL
TRUE PWM frequency reduction is active
bMctrlIxtOverload
BOOL
Status of the Device overload monitoring (Ixt)
TRUE Device utilisation (Ixt) ≥ device utilisation threshold (C00123)
• Lenze setting: C00123
= 100 %
nMctrlIxtRate_a
INT
Current device utilisation (Ixt)
• Scaling: 16384 ≡ 100 %
