Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1235
16 Working with the FB Editor
16.4 Reconfiguring the predefined interconnection
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
• The buttons serve to execute the following functions:
16.4.7 Resetting changed interconnection
If you only made changes on the I/O level, you can reset them by selecting a predefined control
scheme in C00007
. If you have also made changes on the application level, you must first reset the
changed application to a predefined application in C00005
.
How to reset the application interconnection to a predefined application:
1. Go to the Application parameters tab.
2. Select the required application in the Application list field.
How to reset the I/O interconnection to a predefined control scheme:
1. Go to the Application parameters tab.
2. Select the required control scheme in the Control source list field.
Button Function
Paste Add elements selected in the list to the target interconnection
• Only possible if at least one element in the list has been selected for insertion.
• Insertion is also possible via the <Enter> button if at least one element is selected from
the list for insertion.
• The original layout and the relative position of the inserted blocks to each other are
maintained.
• When copying across the devices, you also insert the corresponding separate technical
objects (e.g. port definition).
• The added elements are simultaneously deleted from the list. The connections are added
depending on the selected option.
Close Close dialog box.
•You can also use <Esc> or <Enter> to close the dialog box if "Insert" is not active.
• The elements inserted into the target interconnection so far are maintained.
• The connections for the blocks inserted so far are inserted depending on the selected
option.
