17 Function library
17.1 Function blocks | L_Negation_2
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.1.108 L_Negation_2
This FB converts the sign of the input signal, i.e. the input signal is multiplied by the value -1 and is
then output.
• With the value - 32768 at the nIn_a input, the value + 32767 is provided at the nOut_a output.
Inputs
Outputs
Designator
Data type
Value/meaning
nIn_a
INT
Input signal
Designator
Data type
Value/meaning
nOut_a
INT
Output signal
/B1HJDWLRQB
Q,QBD Q2XWBD


