Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1534
17 Function library
17.2 System blocks | LS_DisFree_a
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.2.9.1 Display of internal process factors in application units
This function extension is available from version 06.00.00!
In addition to the display in percent in C00482/1...8
, for the first four analog signals
nDis1_a ... nDis4_a the configurable display parameters C00487/1...4
are provided. Via these
display parameters, internal process variables can be displayed, e.g. on the keypad, with an
individual scaling and an individual unit (from keypad version 02.01).
Configuration of the display parameters (C00487/1...4
):
[17-79] Formula for scaling the display
Example 1:
•Input variable nDis1_a = 100 %
• Offset 1 (C00484/1
) = 0 %
•Display factor 1 (C00485/1
) = 123.45
•Text 1 (C00486/1
) = "parts"
Example 2:
•Input variable nDis2_a = 40 %
• Offset 2 (C00484/2
) = 35 %
•Display factor 2 (C00485/2
) = 20
•Text 2 (C00486/2
) = "kg"
Parameters Possible settings Info
C00484/1...4
-199.99 % 199.99 Offset 1 ... 4
• See formula [17-79]
.
• Lenze setting: 0.00 %
C00485/1...4
-65536.0000 65536.0000 Display factor 1 ... 4
• Scaling of the input variable for
the display.
• See formula [17-79]
.
• Lenze setting: 1.0000
C00486/1...4
String
(max. 7 digits)
Text 1 ... 4
• For each display value, an
individual unit (e.g. "parts") can be
set.
User unit 1
nDis1_a [%] Offset 1 [%]+
100 [%]
--------------------------------------------------------------------
Display factor 1 [text 1]⋅=
User unit 1
100 [%] 0 [%]+
100 [%]
---------------------------------------
123.45 [parts]⋅ 123.45 parts==
User unit 2
40 [%] 35 [%]+
100 [%]
---------------------------------------
20 [kg]⋅ 15.00 kg==
