Lenze 8400 User Manual

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1438
17 Function library
17.1 Function blocks | L_NSet_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.1.118.1 Main setpoint path
• The signals in the main setpoint path are limited to a value range of ±32767.
• The signal at nNSet_a is first led via the JOG selection function.
• A selected JOG value switches the nNSet_a input inactive. Then, the subsequent signal
conditioning operates with the JOG value.
17.1.118.2 JOG setpoints
In addition to the direct main setpoint selection via the nNSet_a input, so-called JOG setpoints can
be preset in C00039/1...15
.
• The JOG setpoints are binary-coded and can be called using the bJog1 ... bJog8 selection inputs
so that 15 options are available:
• The number of selection inputs to be assigned depends on the number of JOG setpoints
required:
Selection inputs Main setpoint
Main setpoint
bJog8 bJog4 bJog2 bJog1
FALSE FALSE FALSE FALSE nNset_a
FALSE FALSE FALSE TRUE C00039/1
FALSE FALSE TRUE FALSE C00039/2
FALSE FALSE TRUE TRUE C00039/3
FALSE TRUE FALSE FALSE C00039/4
FALSE TRUE FALSE TRUE C00039/5
FALSE TRUE TRUE FALSE C00039/6
FALSE TRUE TRUE TRUE C00039/7
TRUE FALSE FALSE FALSE C00039/8
TRUE FALSE FALSE TRUE C00039/9
TRUE FALSE TRUE FALSE C00039/10
TRUE FALSE TRUE TRUE C00039/11
TRUE TRUE FALSE FALSE C00039/12
TRUE TRUE FALSE TRUE C00039/13
TRUE TRUE TRUE FALSE C00039/14
TRUE TRUE TRUE TRUE C00039/15
Number of JOG setpoints required Number of selection inputs to be assigned (bJog1 ... bJog8)
1At least 1
2 ... 3 at least 2
4 ... 7 at least 3
8 ... 15 4
