8 Basic drive functions (MCK)
8.7 Manual jog
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
8.7.1.1 Functional settings
In C01230, various functional settings for manual jogging can be carried out in bit-coded form.
Function Lenze setting
Bit 0 Manual jog with breakpoint
During manual jog, a stop is automatically made at the breakpoint positions
set in C01234/1...4
.
• The home position must be known for this function.
• Travelling is continued when the pushbutton is "released" and pressed
again. This button has been assigned the ManJogPos and/or ManJogNeg
control function.
Off
Bit 1 Time-based start of second speed
In manual jog mode, an automatic changeover to manual speed 2 takes
place after a parameterisable waiting time.
Time-based start of second speed
( 577)
Off
Bit 2 HW limit switch on
In the "manual jog" operating mode, a travel range monitoring mode via
hardware limit switch is active.
Limit position monitoring
( 536)
Off
Bit 3 SW limit switch on
In the "manual jog" operating mode, a travel range monitoring mode via
parameterised software limit positions.
Limit position monitoring
( 536)
Off
Bit 4 Reserved Off
Bit 5 Maximum jerk
Setting or activation of maximum jerk for traversing profiles
( 550)
Off
Bit 6 Reserved Off
Bit 7 Position controller off
In the "manual jog" operating mode, the position controller is deactivated.
Thus, the compensation of the following error is switched off.
Off
