7 Technology applications
7.2 TA "Actuating drive speed"
394
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.2.4 Process data assignment for fieldbus communication
The fieldbus communication is connected (preconfigured) to the previously selected technology
application by selecting the corresponding control mode in C00007
:
•"30: CAN
" for the connection to the system bus (CAN)
•"40: MCI
" for the connection to a plugged-on communication module (e.g. PROFIBUS)
The assignment of the process data words depends only on the application, not on the bus system
used:
Input words Name Assignment
Word 1 DriveControl Control word
• For bit assignment see the table below.
Word 2 MainSetValue Speed setpoint
• Scaling: 16384 ≡ 100 % reference speed (C00011
)
Word 3 - Not preconfigured
Word 4 - Not preconfigured
Words 5 ... 16 - Not preconfigured
• Only available in control mode "40: MCI".
Control word Name Function
Bit 0 SwitchOn 1 ≡ Change to the "SwitchedOn
" device status
• This bit must be set in the CAN/MCI control word to ensure
that the device changes to the "SwitchedOn
" device status
after mains connection without the need for a master control
specifying this bit via fieldbus.
• If control via a bus system is not wanted (e.g. in the case of
control via terminals), the wDriveCtrl output signal of the
LS_ParFix
system block can be connected to the control word
inputs.
Bit 1 DisableVoltage 1 ≡ Inhibit inverter control (pulse inhibit)
Bit 2 SetQuickStop 1 ≡ Activate quick stop (QSP).
Activate/deactivate quick stop
( 107)
Bit 3 EnableOperation 1 ≡ Enable inverter (RFR)
• If control via terminals is performed, this bit must be set both
in the CAN control word and in the MCI control word.
Otherwise, the controller is inhibited.
Enable/inhibit inverter
( 106)
Bit 4 ModeSpecific_1 Reserved (currently not assigned)
Bit 5 ModeSpecific_2
Bit 6 ModeSpecific_3
Bit 7 ResetFault 1 ≡ Reset fault (trip reset)
• Acknowledge error message (if the error cause has been
eliminated).
Reset error
( 110)
Bit 8 SetHalt 1 ≡ Activate stop function
• Stop drive via stopping ramp (in preparation).
Bit 9 reserved_1 Reserved (currently not assigned)
Bit 10 reserved_2
Bit 11 SetDCBrake 1 ≡ Activate DC-injection braking
Manual DC-injection braking (DCB)
( 268)
Bit 12 JogSpeed1 Activation of fixed speed 1 ... 3
Bit 13 JogSpeed2
