9 Diagnostics & error management
9.5 Logbook
636
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.5.5 Exporting logbook entries to a file
How to export the logbook entries to a file:
1. Click Export... in the Logbook dialog box.
•The Export logbook dialog box is displayed.
2. Specify the folder, file name, and file type for the file.
3. Click the Save button to export the logbook entries into the given file.
• Hidden logbook entries are not exported, i.e. the filter criteria specified are accounted for
during the export.
• The logbook entries are written to the file in the form of a semicolon separated list.
Button Function
Delete Filter Reset set filter criteria to display all available logbook entries.
Export... Export the entries available in the logbook into a *.log file.
Exporting logbook entries to a file
( 636)
Storing in the project File the current logbook in the Engineer project to be able to access it offline,
too.
Storing the logbook in the project
( 637)
Delete Delete all entries available in the logbook.
Configuration of... Open parameterisation dialog for configuring the logbook.
>> more details Show more details:
• Analog value 1, digital values 1 & 2
• More output types of the error numbers (32-bit, internal 32-bit and
internal 16-bit).
•Instead of the >> more details button, the << less details is now displayed
via which the details can be hidden again.
Help Open online help for the logbook.
Resetting an error Acknowledge existing error message if the error cause has been eliminated
and thus the error is not pending anymore.
• After the reset (acknowledgement) of the current error, further errors
may be pending which must also be reset.
Close Close the Logbook dialog box again.
