Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 195
5 Motor control (MCTRL)
5.7 Sensorless vector control (SLVC)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.7.2 Types of control
The sensorless vector control can be operated in two different modes:
• Speed control with torque limitation
(bTorquemodeOn = FALSE)
• Torque control with speed limitation
(bTorquemodeOn = TRUE)
5.7.2.1 Speed control with torque limitation
When bTorquemodeOn = FALSE, the drive system is operated with a selected speed setpoint in a
speed-controlled manner.
The operational performance can be adapted in the following ways:
A. Overload limitation in the drive train
B. Motor current limitation
C. Slip compensation
Overload limitation in the drive train
The torque is limited via the torque setpoint.
• The torque setpoint is identical to the value at the output of the speed controller,
nOutputSpeedCtrl.
• To avoid overload in the drive train, the torque in motor mode can be limited via the
nTorqueMotLimit_a process input signal, and the torque in generator mode can be limited via
the nTorqueGenLimit_a process input signal:
 Note!
From version 13.00.00, the torque setpoint nSpeedSetValue_a is set to 0 by quick stop
(QSP) device-internally and the torque limit values nTorqueMotLimit_a and
nTorqueGenLimit_a are set to 100 % to stop the drive quickly and safely anytime. The
previous behaviour can be set in C2865/1
via bit 12 and bit 13.
Designator
DIS code | data type
Information/possible settings
nTorqueMotLimit_a
C00830/29 | INT
Torque limitation in motor mode
• Scaling: 16384 ≡ 100 % M
max
(C00057)
• Setting range: 0 … +199.99 %
• If keypad control is performed: Parameterisable via C00728/1
.
nTorqueGenLimit_a
C00830/28 | INT
Torque limitation in generator mode
• Scaling: 16384 ≡ 100 % M
max
(C00057)
• Setting range: -199.99 ... 0 %
• If keypad control is performed: Parameterisable via C00728/2
.
 Note!
To avoid instabilities during operation, the torque limit values are internally processed
as absolute values.
