17.2.19 LS_ParFree_a
This system block outputs 16 parameterisable analog signals.
Outputs
Parameters
Designator
Data type
Value/meaning
nPar1_a ... nPar16_a
INT
From version 11.00.00 onwards:
nC472_1_a ... nC472_16_a
Output of the analog signals parameterised in C00472/1...16
• The nPar9_a ... nPar16_a outputs are only available from version 04.00.00.
Note: From version 11.00.00 the outputs are named according to the respective
setting parameter for an easier allocation.
Parameters Possible settings Info
C00472/1...16
-199.99 % +199.99 Selection of analog signals to be
output
