Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 653
9 Diagnostics & error management
9.9 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
9.9.5 Short overview (A-Z)
The table below contains all error messages of the inverter operating system in alphabetical order.
Tip!
If you click the cross-reference in the first column, "Error number", you will reach the
detailed description of the respective error message in the following chapter "Cause &
possible remedies". ( 656)
Note!
For the sake of legibility, the Logbook and C00165 display the 32-bit error number with
the following syntax:
[Error type].[Error subject area no.].[Error ID]
In this documentation, "xx", a wildcard, stands for the error type since it is configurable
for many error messages.
Error number Display in Error message Response
(Lenze setting)
Adjustable
in
CAN
Emergency
Error Code
32 bits 16 bits
hex
16 bits
dec
C00162/1
xx.0125.00001 0x1901 6401 8192001 An01: AIN1_I < 4 mA TroubleQuickStop C00598/1 0xF000
xx.0125.00002
0x1902 6402 8192002 An02: AIN2_I < 4 mA TroubleQuickStop C00598/2 0xF000
xx.0131.00006
0x1f06 7942 8585222 CA06: CAN CRC error No Reaction C00592/1 0x8000
xx.0131.00007
0x1f07 7943 8585223 CA07: CAN Bus Warn No Reaction C00592/3 0x8000
xx.0131.00008
0x1f08 7944 8585224 CA08: CAN Bus Stopped No Reaction C00592/4 0x8000
xx.0131.00011
0x1f0b 7947 8585227 CA0b: CAN HeartBeatEvent No Reaction C00592/5 0x8130
xx.0131.00015
0x1f0f 7951 8585231 CA0F: CAN control word Fault C00594/1 0xF000
xx.0127.00002
0x1b02 6914 8323074 CE04: MCI communication error No Reaction C01501/1 0x7000
xx.0127.00015
0x1b0f 6927 8323087 CE0F: MCI control word Fault C00594/2 0xF000
xx.0135.00001
0x2301 8961 8847361 CE1: CAN RPDO1 No Reaction C00593/1 0x8100
xx.0135.00002
0x2302 8962 8847362 CE2: CAN RPDO2 No Reaction C00593/2 0x8100
xx.0135.00003
0x2303 8963 8847363 CE3: CAN RPDO3 No Reaction C00593/3 0x8100
xx.0131.00000
0x1f00 7936 8585216 CE4: CAN Bus Off No Reaction C00592/2 0x8000
xx.0135.00004
0x2304 8964 8847364 CE5: CAN RPDO4 No Reaction C00593/4 0x8100
xx.0140.00013
0x280d 10253 9175053 CI01: Module missing/incompatible No Reaction C01501/2 0x7000
xx.0184.00001
0x5401 21505 12058625 Ck01: Pos. HW limit switch TroubleQuickStop C00595/1 0x8600
xx.0184.00002
0x5402 21506 12058626 Ck02: Neg. HW limit switch TroubleQuickStop C00595/2 0x8600
xx.0184.00007
0x5407 21511 12058631 Ck03: Pos. SW limit position TroubleQuickStop C00595/3 0x8600
xx.0184.00008
0x5408 21512 12058632 Ck04: Neg. SW limit position TroubleQuickStop C00595/4 0x8600
xx.0184.00153
0x5499 21657 12058777 Ck05: Error following error 1 Warning C00595/5 0x8611
xx.0184.00154
0x549a 21658 12058778 Ck06: Error following error 2 Warning C00595/6 0x8611
xx.0184.00155
0x549b 21659 12058779 Ck07: Traversing range limit exceeded TroubleQuickStop C00595/7 0x8612
xx.0184.00156
0x549c 21660 12058780 Ck08: Reference position unknown WarningLocked C00595/8 0x8612
xx.0184.08005
0x54cd 21709 12066629 Ck09: Positioning mode invalid WarningLocked C00595/9 0x8600
xx.0184.08007
0x54cf 21711 12066631 Ck10: Profile data implausible WarningLocked C00595/10 0x8600
xx.0184.08009 0x54d1 21713 12066633 Ck11: Operating mode invalid Warning C00595/11 0x8600
xx.0184.08014
0x54d6 21718 12066638 Ck12: Profile number invalid WarningLocked C00595/12 0x8600
xx.0184.08015
0x54d7 21719 12066639 Ck13: Error FB MCKCtrlInterface Warning C00595/13 0x8600
xx.0184.00015 0x540f 21519 12058639 Ck14: Target position outside SW limit position WarningLocked C00595/14 0x8600
xx.0184.00005
0x5405 21509 12058629 Ck15: Error message sig. brake TroubleQuickStop -0x8600
xx.0184.00064
0x5440 21568 12058688 Ck16: Time overrun manual operation Fault -
