17.1.53 L_ConvW_3
This FB serves to convert analog signal forms. The following conversions per parameter can be
selected:
•[%]  [incr/ms]
•[incr/ms]  [%]
• Conversion via parameterisable factors
• Input signal is passed through without conversion
Inputs
Outputs
Parameters
Designator
Data type
Information/possible settings
wIn
WORD
Input signal
Designator
Data type
Value/meaning
wOut
WORD
Output signal
Parameters Possible settings Info
C00940/3
-32767 32767 Numerator
•Lenze setting: 1
C00941/3
-32767 32767 Denominator
•Lenze setting: 1
C00942/3
Selection of the conversion
0 wOut = wIn (no conversion)
1[%]  [incr/ms]
2[incr/ms]  [%]
3 wOut = wIn * C00940
/ C00941
 For conversion formulae see L_ConvW_1.
