3 Commissioning
3.3 Preconditions for commissioning with the »Engineer«
54
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.3 Preconditions for commissioning with the »Engineer«
For commissioning, you need
• a PC that meets the following system requirements:
• a processor with 1.4 GHz or higher
• at least 512 MB RAM and 650 MB free hard disc space
• Microsoft® Windows® 2000 operating system (from service pack 2 onwards) or
Windows® XP
• the Lenze »Engineer« PC software
• a connection to the inverter, e.g. via a USB diagnostic adapter:
• connect the USB diagnostic adapter to the X6 diagnostic interface.
• establish a connection between the USB diagnostic adapter and the PC via a free USB port.
 Tip!
How to obtain/update the »Engineer« software:
• Download from the internet: The full version of the »Engineer StateLevel« is provided
free of charge in the internet:
http://www.Lenze.com
 Download  Software downloads
• Requesting the CDYou can also request the »Engineer« separately on CD free of charge
at your Lenze representative. See the "About Lenze" area on our homepage for e.g. the
corresponding German address.

Lenze 8400 Specifications

General

Category	DC Drives
Series	8400
Protection class	IP20
Control Type	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Input Voltage	AC 230/400/480 V
