15.6 Selection list - angle signals
This selection list is relevant for the following
configuration parameters:
Parameters
C00622 System connection list: Angle
C00712
LA_TabPos: phi connection list
Selection list - angle signals
0 Not connected
1005 LA_NCtrl: dnFreeOut1_p
1006 LA_NCtrl: dnFreeOut2_p
1100 LA_TabPos: dnTargetPos_p
1101 LA_TabPos: dnSetPos_p
1102 LA_TabPos: dnFreeOut1_p
1103 LA_TabPos: dnFreeOut2_p
1104 LA_TabPos: dnPosAct_p
1105 LA_TabPos: dnDeltaPosAct_p
1205 LA_SwitchPos: dnFreeOut1_p
1206 LA_SwitchPos: dnFreeOut2_p
16000 LP_CanIn1: dnIn34_p
16001 LP_CanIn2: dnIn34_p
16002 LP_CanIn3: dnIn34_p
16003 LP_MciIn: dnIn34_p
16006 LP_CanIn1: dnIn12_p
16007 LP_CanIn2: dnIn12_p
16008 LP_CanIn3: dnIn12_p
16009 LP_MciIn: dnIn56_p
16010 LP_MciIn: dnIn78_p
16011 LP_CanIn4: dnIn12_p
16012 LP_CanIn4: dnIn34_p
17020 LS_DigitalInput: dnPosIn12_p
17101 LS_TouchProbe: dnTPDigIn1_Position_p
17102 LS_TouchProbe: dnTPDigIn2_Position_p
17103 LS_TouchProbe: dnTPDigIn3_Position_p
17104 LS_TouchProbe: dnTPDigIn4_Position_p
17105 LS_TouchProbe: dnTPDigIn5_Position_p
17106 LS_TouchProbe: dnTPDigIn6_Position_p
17107 LS_TouchProbe: dnTPDigIn7_Position_p
17120 LS_RetainData: dnOut1
17121 LS_RetainData: dnOut2
17122 LS_RetainData: dnOut3
17123 LS_RetainData: dnOut4
20000 LS_ParFree_p: dnC474_1_p
20001 LS_ParFree_p: dnC474_2_p
20002 LS_ParFree_p: dnC474_3_p
20003 LS_ParFree_p: dnC474_4_p
20004 LS_ParFree_p: dnC474_5_p
20005 LS_ParFree_p: dnC474_6_p
20006 LS_ParFree_p: dnC474_7_p
20007 LS_ParFree_p: dnC474_8_p
20008 LS_ParFree32: dnC479_1
20009 LS_ParFree32: dnC479_2
20010 LS_ParFree32: dnC479_3
20011 LS_ParFree32: dnC479_4
20012 LS_ParFree32: dnC479_5
20013 LS_ParFree32: dnC479_6
20014 LS_ParFree32: dnC479_7
20015 LS_ParFree32: dnC479_8
20016 LS_ParFreeUnit_1: dnC475_1
20017 LS_ParFreeUnit_1: dnC475_2
20018 LS_ParFreeUnit_1: dnC475_3
20019 LS_ParFreeUnit_1: dnC475_4
20020 LS_ParFreeUnit_1: dnC475_5
20021 LS_ParFreeUnit_1: dnC475_6
20022 LS_ParFreeUnit_1: dnC475_7
20023 LS_ParFreeUnit_1: dnC475_8
20024 LS_ParFreeUnit_1: dnC475_9
20025 LS_ParFreeUnit_1: dnC475_10
20026 LS_ParFreeUnit_1: dnC475_11
20027 LS_ParFreeUnit_1: dnC475_12
20028 LS_ParFreeUnit_1: dnC475_13
20029 LS_ParFreeUnit_1: dnC475_14
20030 LS_ParFreeUnit_1: dnC475_15
20031 LS_ParFreeUnit_1: dnC475_16
20032 LS_ParFreeUnit_2: dnC475_17
20033 LS_ParFreeUnit_2: dnC475_18
20034 LS_ParFreeUnit_2: dnC475_19
20035 LS_ParFreeUnit_2: dnC475_20
20036 LS_ParFreeUnit_2: dnC475_21
20037 LS_ParFreeUnit_2: dnC475_22
20038 LS_ParFreeUnit_2: dnC475_23
20039 LS_ParFreeUnit_2: dnC475_24
20040 LS_ParFreeUnit_2: dnC475_25
20041 LS_ParFreeUnit_2: dnC475_26
20042 LS_ParFreeUnit_2: dnC475_27
20043 LS_ParFreeUnit_2: dnC475_28
20044 LS_ParFreeUnit_2: dnC475_29
20045 LS_ParFreeUnit_2: dnC475_30
20046 LS_ParFreeUnit_2: dnC475_31
20047 LS_ParFreeUnit_2: dnC475_32
32000 LS_MotorInterface: dnMotorPosAct_p
32001 LS_MotorInterface: dnMotorDeltaPosAct_p
32200 LS_MotionControlKernel: dnPosTarget_p
32201 LS_MotionControlKernel: dnPosSetValue_p_
32202 LS_MotionControlKernel: dnDeltaPos_p_
32203 LS_MotionControlKernel: dnMotorRefOffset_p_
32204 LS_MotionControlKernel: dnPosSet_p
32205 LS_MotionControlKernel: dnPosSetRelative_p
32206 LS_MotionControlKernel: dnPosCycle_p
36040 L_ArithmetikPhi_1: dnOut_p
36046 L_GainOffsetPhiP_1: dnOut_p
