17.1.107 L_Negation_1
This FB converts the sign of the input signal, i.e. the input signal is multiplied by the value -1 and is
then output.
• With the value - 32768 at the nIn_a input, the value + 32767 is provided at the nOut_a output.
Inputs
Outputs
Designator
Data type
Value/meaning
nIn_a
INT
Input signal
Designator
Data type
Value/meaning
nOut_a
INT
Output signal
