Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 783
12 Fieldbus interface (MCI)
12.2 Control mode "MCI"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
12.2 Control mode "MCI"
"40: MCI" can be selected as a control mode in C00007 in order to quickly and easily set-up inverter
control by means of MCI-PDOs via the fieldbus interface.
Given that the technology applications are fundamentally different and have different
requirements regarding the signals sent to them, predefined assignment of the MCI-PDOs depends
on the technology application selected in C00005
:
• TA "Actuating drive speed":
Process data assignment for fieldbus communication
( 394)
• TA "Table positioning":
Process data assignment for fieldbus communication
( 458)
• TA "Abschaltpositionierung":
Process data assignment for fieldbus communication
( 484)
 Tip!
The predefined assignment of the MCI-PDOs can be parameterised by means of PDO
mapping and can be freely configured on the I/O level in the function block editor (FB
editor).

Lenze 8400 Specifications

General

Category	DC Drives
Series	8400
Protection class	IP20
Control Type	Vector control
Communication	CANopen, PROFIBUS, Ethernet
Protection Features	Overcurrent, overvoltage, undervoltage, overtemperature
Input Voltage	AC 230/400/480 V
