Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 797
14 Parameter change-over
14.3 Configuring the motor data parameter list by means of parameterisation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.3 Configuring the motor data parameter list by means of parameterisation
The setting of the values for value sets 1 ... 4 of the motor data parameter list can also be carried out
directly via the codes from code C02210
(see following table; columns 1st value ... 4th value).
• Unlike the "definable" parameter list, the motor data parameter list has a fixed assignment to
the motor and control parameters.
• The preset values for value sets 1 ... 4 correspond to the Lenze setting of the respective motor or
control parameter.
• The values are entered according to the scaling format / scaling factor of the respective motor
or control parameter.
Code Name Lenze setting 1st value 2nd value 3rd value 4th value
C00006 Motor control 6 C02210/1 C02210/2 C02210/3 C02210/4
C00015 VFC: V/f base frequency 50.0 Hz C02212/1 C02212/2 C02212/3 C02212/4
C00016 VFC: Vmin boost 1.60 % C02213/1 C02213/2 C02213/3 C02213/4
C00018 Switching frequency 2 C02214/1 C02214/2 C02214/3 C02214/4
C00019 Auto-DCB: Threshold 3 rpm C02215/1 C02215/2 C02215/3 C02215/4
C00021 Slip comp. 2.67 % C02216/1 C02216/2 C02216/3 C02216/4
C00022 Imax in motor mode 47.00 A C02217/1 C02217/2 C02217/3 C02217/4
C00023 Imax in generator mode 100.00 % C02218/1 C02218/2 C02218/3 C02218/4
C00036 DC braking: Current 50.00 % C02219/1 C02219/2 C02219/3 C02219/4
C00070/1 SLVC: Vp speed controller 15.00 C02220/1 C02220/2 C02220/3 C02220/4
C00070/2 SC: Vp speed controller 6.00 C02220/5 C02220/6 C02220/7 C02220/8
C00070/3 SLPSM: Vp speed controller 3.00 C02220/9 C02220/10 C02220/11 C02220/12
C00071/1 SLVC: Ti speed controller 100.0 ms C02221/1 C02221/2 C02221/3 C02221/4
C00071/2 SC: Ti speed controller 50.0 ms C02221/5 C02221/6 C02221/7 C02221/8
C00071/3 SLPSM: Ti speed controller 100.0 ms C02221/9 C02221/10 C02221/11 C02221/12
C00072 SC: Tdn speed controller 0.00 ms C02222/1 C02222/2 C02222/3 C02222/4
C00073/1 VFC: Vp Imax controller 0.25 C02223/1 C02223/2 C02223/3 C02223/4
C00073/2 SLVC: Vp torque controller 1.25 C02223/5 C02223/6 C02223/7 C02223/8
C00074/1 VFC: Ti Imax controller 65 ms C02224/1 C02224/2 C02224/3 C02224/4
C00074/2 SLVC: Ti torque controller 30 ms C02224/5 C02224/6 C02224/7 C02224/8
C00075 Vp current controller 7.00 V/A C02225/1 C02225/2 C02225/3 C02225/4
C00076 Ti current controller 10.61 ms C02226/1 C02226/2 C02226/3 C02226/4
C00077 SC: Vp field controller 12.80 C02227/1 C02227/2 C02227/3 C02227/4
C00078 SC: Tn field controller 256.0 ms C02228/1 C02228/2 C02228/3 C02228/4
C00079/1 SC: Current controller - feedforward control 0 C02229/1 C02229/2 C02229/3 C02229/4
C00079/2 SC: adapt. field weak. controller 1 C02229/5 C02229/6 C02229/7 C02229/8
C00079/3 SC: n-Ctrl Anti-Wind-Up 0 C02229/9 C02229/10 C02229/11 C02229/12
C00080 Override point of field weakening 0 Hz C02230/1 C02230/2 C02230/3 C02230/4
C00081 Rated motor power 11.00 kW C02231/1 C02231/2 C02231/3 C02231/4
C00082 Motor rotor resistance 276 mOhm C02232/1 C02232/2 C02232/3 C02232/4
C00084 Motor stator resistance 330 mOhm C02233/1 C02233/2 C02233/3 C02233/4
C00085 Motor stator leakage inductance 3.50 mH C02234/1 C02234/2 C02234/3 C02234/4
C00087 Rated motor speed 1460 rpm C02236/1 C02236/2 C02236/3 C02236/4
C00088 Rated motor current 21.00 A C02237/1 C02237/2 C02237/3 C02237/4
C00089 Rated motor frequency 50 Hz C02238/1 C02238/2 C02238/3 C02238/4
C00090 Rated motor voltage 400 V C02239/1 C02239/2 C02239/3 C02239/4
C00091 Motor cosine phi 0.85 C02240/1 C02240/2 C02240/3 C02240/4
C00092 Motor magnetising inductance 81.0 mH C02241/1 C02241/2 C02241/3 C02241/4
C00095 Motor magnetising current 8.50 A C02242/1 C02242/2 C02242/3 C02242/4
C00106 Auto-DCB: Hold time 0.500 s C02244/1 C02244/2 C02244/3 C02244/4
C00107 DC braking: Hold time 999.000 s C02245/1 C02245/2 C02245/3 C02245/4
