Lenze 8400 User Manual

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1532
17 Function library
17.2 System blocks | LS_DisFree
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
17.2.8 LS_DisFree
This system block displays 8 arbitrary 16-bit signals of the application on display codes.
Inputs
Parameters
 For a detailed description see the main chapter "I/O terminals":
Internal interfaces | System block "LS_DigitalOutput"
( 346)
Designator
Data type
Information/possible settings
wDis1 ... wDis8
WORD
From version 11.00.00 onwards:
wC481_1 ... wC481_8_a
Inputs for any 16-bit signals of the application
Note: From version 11.00.00 the inputs are named according to the display
parameter for an easier allocation.
Parameters Possible settings Info
C00481/1...8
0x0000 0xFFFF Display of the 16-bit signals which
are applied at the wDis1 ... wDis8
inputs
Z'LV
Z'LV
Z'LV
Z'LV
Z'LV
Z'LV
Z'LV
Z'LV
&
&
&
&
&
&
&
&
/6B'LV)UHH
