15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
15.2 Parameter list
This chapter lists all parameters of the operating system in numerically ascending order.
C00001
C00002
Note!
The parameter descriptions are based on the software version V16.00.00.
Parameter | Name:
C00001 | Keypad Userlevel
Data type: UNSIGNED_8
Index: 24574
d
= 5FFE
h
From version 12.00.00 onwards, the extent of menus, submenus and codes shown in the keypad can be adapted by
selecting the "userlevel".
• When the userlevel has been changed, the menus of the keypad will be reconfigured according to the selected
user level.
• Independently of the set userlevel, the parameters of the attached communication module will always be
displayed completely.
Selection list Info
10 Standard Only the most important menus and codes are displayed
on the keypad.
20 Expert All menus and codes are displayed on the keypad.
30 Service Only for servicing purposes (Lenze service).
Subcodes Lenze setting Info
C00001/1 10: Standard Keypad UserLevel
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00002 | Device command
Data type: UNSIGNED_8
Index: 24573
d
= 5FFD
h
Note:
• Before switching off the supply voltage after a device command has been executed, check the successful
execution of the device command via the status display in C00003
!
• Before activating device commands by a master control, wait for the "Ready" signal of the inverter.
• The device will reject a write process to C00002/x if the value is >1 and issue an error message.
Drive control (DCTRL)
: Device commands
Selection list
0Off / ready
1On / start
4 Action cancelled
5No access
6 No access controller inhibit
20 20% working
40 40% working
60 60% working
80 80% working
Subcodes Lenze setting Info
