Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 249
5 Motor control (MCTRL)
5.9 Servo control (SC)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.9.4.5 Adapting the max. acceleration change (jerk limitation)
In the default setting of 400 %/ms of the max. acceleration change (C00274), jerk limitation is
switched off.
The setting defines the permissible maximum torque change per ms (based on the rated motor
torque).
Via the max. acceleration change that can be set in C00274
, the change of the
setpoint torque can be limited for jerk limitation. Hence, sudden torque step
changes can be avoided. The entire speed characteristic is smoothed.
Parameters Info Lenze setting
Value Unit
C00274 SC: Max. change in acceleration 400.0 %/ms
 Note!
Only activate this jerk limitation for speed-controlled applications!
If table positioning or a free function block interconnection with a positioning operating
mode is selected, jerk limitation must be switched off.
• Here, jerk limitation is provided for in the travel profile generator. Setting this jerk
limitation in the motor control would lead to following errors!
