Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 89
3 Commissioning
3.10 PC manual control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.10 PC manual control
This function extension is available from version 06.00.00 onwards and is supported by the
»Engineer« from version 2.13 onwards!
For the purpose of testing and demonstration and when an online connection has been established,
the PC manual control enables the manual control of various drive functions from the »Engineer«.
Supported drive functions:
• Speed control (follow speed setpoint)
• Activate/deactivate quick stop
• Set/reset home position
• Manual jog
• Positioning (relative or absolute)
More control functions:
• Reset error message
• Set digital/analog outputs (in preparation)
Diagnostic functions:
• Display of the actual speed value and motor current (as time characteristic)
• Display of the current device status
• Display of the status determining error
• Display of the status of the digital/analog inputs (in preparation)
3.10.1 Activate PC manual control
 Stop!
PC manual control must be explicitly activated by the user.
If PC manual control is activated, the inverter is inhibited via device command
(C00002/16
) first.
