Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 651
9 Diagnostics & error management
9.9 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Error ID
8-bit value (0 ... 255) for error identification within the error subject area.
 Tip!
All possible 16-bit error numbers are listed in the table entitled "Short overview (A-Z)
" in the
second column.
( 653)
9.9.3 Reset error message
An error message with the response "Fault", "Trouble", "TroubleQSP" or "Warning locked" must be
explicitly reset (acknowledged) after the cause of the error has been eliminated.
 To reset (acknowledge) a pending error message, execute device command
C00002/19
="1".
 Tip!
When an online connection to the inverter has been established, use the Diagnostics tab of
»Engineer« and click Reset error to reset a pending error message.
35 CAN process data object (PDO) Errors that are explicitly only related to the CAN-PDO (process data
objects).
Yes
40 Device configuration Errors that occur due to incompatibilities of the plugged-in individual
components (fieldbus module, safety module, et al.).
Yes if the error relates to a
module plugged-in by the
user.
44 Parameter set Errors that occur in connection with the parameter set or the
parameter set memory (memory module).
Yes if the error relates to a
missing or incompatible
memory module.
45 Device firmware (internal error) Internal error of the device firmware. No
54 Fieldbus Errors that occur in connection with fieldbus communication. Yes
84 MotionControlKernel Errors that occur within the MotionControl basic functions (e.g.
profile generation, brake control, positioning).
Yes
100
...
103
User error 1
...
User error 4
Errors generated by the user (by the application) via the
LS_SetError_1
system block.
Yes
104
...
107
User error 5
...
User error 8
Errors generated by the user (by the application) via the
LS_SetError_2
system block.
Yes
Error subject area Assigned errors Remedy possible by
user?
No. Name
814Bit15 07
