Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 707
11 System bus "CAN on board"
11.4 Going online via the system bus
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.4 Going online via the system bus
The integrated system bus interface (CAN on board, X1 terminal) can also be used for the
communication between the »Engineer« and the inverter, alternatively to the USB diagnostic
adapter.
• Lenze offers the following communication accessories for connection to the PC:
11.5 Reinitialising the CANopen interface
The C00002/26 = "1: On / start" device command reinitialises the CANopen interface of the inverter
("Reset node"), which is required after e.g. changing the data transfer rate, the node address or the
identifiers, respectively.
Communication accessories PC interface
PC system bus adapter 2173
incl. connection cable and voltage supply adapter
• for DIN keyboard connection (EMF2173IB)
• for PS/2 keyboard connection (EMF2173IBV002)
• for PS/2 keyboard connection with electrical isolation (EMF2173IBV003)
Parallel interface
(LPT port)
PC system bus adapter 2177
incl. connection cable (EMF2177IB)
USB
(Universal Serial Bus)
 Note!
• For detailed information about the PC system bus adapter, please see the "CAN
Communication Manual".
• Please observe the documentation for the PC system bus adapter!
• In the »Engineer«, go to the Device assignment offline devices dialog box and select the
"System bus CAN" entry from the Bus connection list field to establish an online
connection.
