Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 193
5 Motor control (MCTRL)
5.7 Sensorless vector control (SLVC)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.7.1 Parameterisation dialog/signal flow
 Proceed as follows to open the dialog for parameterising the motor control:
1. »Engineer« Go to the Project view and select the 8400 HighLine inverter.
2. Select the Application parameters tab from the Workspace.
3. Select the motor control "4: SLVC: Vector control" from the Overview dialog level in the
Motor control list field (C00006
):
4. Click the Motor control vector button to change to the Overview  Motor control vector
dialog box.
• This dialog level only shows a simplified signal flow with the most important
parameters.
• When you click the >>More details button in the left-most position, a signal flow with
more details/parameters is displayed, as shown in the following subchapter.
