7 Technology applications
7.2 TA "Actuating drive speed"
396
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.2.5 Setting parameters (short overview)
Parameters Info Lenze setting
Value Unit
C00012 Accel. time - main setpoint 2.000 s
C00013
Decel. time - main setpoint 2.000 s
C00019
Auto-DCB: Threshold 3 rpm
C00024
LS_DriveInterface: bNActCompare 0.00 %
C00036
DCB braking: Current 50.00 %
C00039/1
Fixed setpoint 1 40.00 %
C00039/2 Fixed setpoint 2 60.00 %
C00039/3
Fixed setpoint 3 80.00 %
C00039/4...15
Fixed setpoint 4 ... 15 0.00 %
C00101/1...15 Add. accel. time 1 ... 15 0.000 s
C00103/1...15
Add. decel. time 1 ... 15 0.000 s
C00105
Decel. time - quick stop 2.000 s
C00106
Auto-DCB: Hold time 0.500 s
C00107
DCB braking: Hold time 999.000 s
C00134
L_NSet_1: Ramp smoothing 0: Off
C00182
L_NSet_1: S-ramp time PT1 20.00 s
C00190
L_NSet_1: Setpoint arithmetic 0: Out = Set
C00220
L_NSet_1: Acceleration time - add. setpoint 0.000 s
C00221
L_NSet_1: Deceleration time - add. setpoint 0.000 s
C00222
L_PCTRL_1: Vp 1.0
C00223
L_PCTRL_1: Tn 400 ms
C00224
L_PCTRL_1: Kd 0.0
C00225
L_PCTRL_1: MaxLimit 199.99 %
C00226
L_PCTRL_1: MinLimit -199.99 %
C00227 L_PCTRL_1: Acceleration time 0.010 s
C00228
L_PCTRL_1: Deceleration time 0.010 s
C00233
L_PCTRL_1: Root function 0: Off
C00241 L_NSet_1: Hyst. NSet reached 0.50 %
C00242
Operating mode of process controller 0: Off
C00243
L_PCTRL_1: Accel. time influence 5.000 s
C00244
L_PCTRL_1: Deceleration time influence 5.000 s
C00632/1
L_NSet_1: Blocking speed 1 max 0.00 %
C00632/2
L_NSet_1: Blocking speed 2 max 0.00 %
C00632/3
L_NSet_1: Blocking speed 3 max 0.00 %
C00633/1
L_NSet_1: Blocking speed 1 min 0.00 %
C00633/2
L_NSet_1: Blocking speed 2 min 0.00 %
C00633/3
L_NSet_1: Blocking speed 3 min 0.00 %
C00635
L_NSet_1: nMaxLimit 199.99 %
C00636
L_NSet_1: nMinLimit -199.99 %
C00670
L_OffsetGainP_1: Gain 1.0000
C00671
L_OffsetGainP_2: Gain 1.0000
C00672
L_OffsetGainP_3: Gain 1.0000
