17.1.172 L_Transient_8
This FB serves to evaluate digital signal edges and convert them into timed, retriggerable pulses.
Rising signal edges, falling signal edges or both signal edges can be evaluated.
Inputs
Outputs
Parameters
Designator
Data type
Information/possible settings
bIn
BOOL
Input for edge evaluation
• The function depends on the selection of edge evaluation in C01140/4
.
Designator
Data type
Value/meaning
bOut
BOOL
Output (retriggerable)
Parameters Possible settings Info
C01140/4
Function
• Selection of edge evaluation
0 High edge Lenze setting
1Low edge
2 High and low edge
C01141/4
0.001 s 60.000 Pulse duration
• Lenze setting: 0.001 s
 For a detailed functional description see L_Transient_1.
