Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 81
3 Commissioning
3.9 Commissioning of the "Switch-off positioning" technology application
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.9 Commissioning of the "Switch-off positioning" technology application
[3-3] Block diagram for wiring of the commissioning example for the "Switch-off positioning" application
 Note!
Take all the necessary safety precautions before you carry out the following
commissioning steps and switch the device on!
Safety instructions with regard to commissioning
( 52)
System constellation
X4/RFR Controller enable
X5/DI1 Initiator connection for stop function 1
X5/DI2 Initiator connection for stop function 2
X5/DI3 Quick stop for CW rotation / selection of switch-off position 1
X5/DI4 Quick stop for CCW rotation / selection of switch-off position 2
X6 Diagnostic interface for connecting the USB diagnostic adapter
8400 HighLine
X61
X6
DIAG
AR A1U GA
X3
24I RFR DI1 DI2
X5
DI3 DI4 DI5 DI6 DI7U V W
X6
t [s]
0
1
QSP
Cw
Ccw
-
DI1
DI2
DI1
DI2
v [m/s]
C00039/3
C00012
C00012
C00013
C00039/3
C00013
Cw
Ccw
Cw
Ccw
M
3~
i
0
1
0
0
1
1
