WorkCentre 5225, 5230
ADJ 9.1.1
Launch Version
Repairs and Adjustments
Adjustment
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (UI Diagnostic Mode).
2. Select NVM Read/Write.
3. Adjust the measured values of the Lead (A) and Side Edges (B) using the following NVM
so that the measured values fall within the specifications of the respective supporting
modes.
If the measured value is shorter than specification above (A or B): Set a larger value.
If the measured value is longer than specification above (A or B): Set a smaller value.
• Adjustment of A (Lead Edge), refer to Table 3 below.
• Adjustment of B (Side Edge), refer to Table 4 below.
4. After adjustment, print the test pattern in the same mode and measure the Lead and Side
Edge values. Repeat this procedure until the values fall within the specifications.
5. Repeat the procedure until the measured values of the Lead (A) and Side Edges (B) fall
within the specifications.
Table 3 NVM List of Lead Edge
Chain Link Name Min.
Initia
l
Max Increment
742-027 LEAD REGI ADJUSTMENT - ALL TRAY 0 33 66 0.2175mm
760-001 TRAY1 for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-002 TRAY2-4 for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-003 MPT for Normal Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-005 DUP ALL SIZE for Normal Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-013 DUP A3 Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-014 DUP A4S Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-015 DUP A4L Group - LEAD REGI ADJUST-
MENT
0 10 16 0.363mm
760-016 TRAY1 for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-017 TRAY1 for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-018 TRAY2-4 for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-019 TRAY2-4 for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-020 MPT for Thick-1 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-021 MPT for Thick-2 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-022 DUP ALL SIZE for Thick-1 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-023 DUP ALL SIZE for Thick-2 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
760-24 Tray 2-=4, HCF for Thick-1 Paper-REGI
LOOP TIMER
0 33 66 0.363mm
760-25 Tray3-4, HCF for Thick-2 Paper-REGI
LOOP TIMER
0 33 66 0.363mm
760-031 TRAY1 for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-032 TRAY2-4 for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-033 MPT for Thick-4 Paper - LEAD REGI
ADJUSTMENT
0 33 66 0.363mm
760-034 DUP ALL SIZE for Thick-4 Paper - LEAD
REGI ADJUSTMENT
0 33 66 0.363mm
Table 4 NVM List of Side Edge
Chain Link Name Min.
Initia
l
Max Increment
749-001 ALL TRAY-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-002 TRAY1-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-003 TRAY2-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-004 TRAY3-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-005 TRAY4-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-007 MPT-LASER SIDE REGI ADJUSTMENT 1 50 99 0.254mm
749-009 DUP ALL TRAY-LASER SIDE REGI
ADJUSTMENT
1 50 99 0.254mm
749-010 DUP TRAY1-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-011 DUP TRAY2-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-012 DUP TRAY3-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-013 DUP TRAY4-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
749-015 DUP MPT-LASER SIDE REGI ADJUST-
MENT
1 50 99 0.254mm
Table 3 NVM List of Lead Edge
Chain Link Name Min.
Initia
l Max Increment
To Next Page
