Xerox WorkCentre 5230 User Manual

February, 2008
6-115
WorkCentre 5225, 5230
Initialize HFSI Counters
General Procedures
Launch Version
Initialize HFSI Counters
Purpose
Initialize the HFSI Counter.
Procedure
Reading and resetting HFSI
1. Access Diagnostic Routines.
a. Enter UI Diagnostics (UI Diagnostic Mode).
2. Select Adjustment/Other.
3. Select HFSI Counter.
4. Reset Correct Value
a. Enter the Chain-Link Number
b. Select Reset Correct Value. Diagnostics routine completed will be displayed
NOTE: Diagnostics routine completed will be displayed. The HFSI Counter is reset.
HFSI
Table 1 IOT HFSI
Chain-Link Name
Initial
Value
Value 1Count Remarks
954-807 Last 2Digits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-807 5th&6thDigits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-807 3rd&4thDigits of Fuser discharging Number 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-807 First 2Digits of Fuser discharging Number 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-800 Tray1 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-800 Tray1 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-800 Tray1 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-800 Tray1 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-801 Tray2 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-801 Tray2 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-801 Tray2 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-801 Tray2 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-802 Tray3 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-802 Tray3 5th&6thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-802 Tray3 3rd&4thDigits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-802 Tray3 First 2Digits of Feed Capacity (8 Digits) 0 0~3 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
954-803 Tray4 Last 2Digits of Feed Capacity (8 Digits) 0 0~99 1 Only 0 clearance is possible in the write mode.(“0 clearance” means all bytes
changes 0 at the same time.)
