Xerox WorkCentre 5230 User Manual

February, 2008
2-617
WorkCentre 5225, 5230
116-380, 116-381
Status Indicator Raps
Launch Version
116-380 ESS Font ROM DIMM #1 RAP
An error is detected when the Font ROM DIMM #1 was checked.
Initial Actions
Power Off/On
Procedure
Pull out and insert the Printer PWB (PL 9.2) and the PS DIMM (PL 9.2) Switch on the power.
The problem persists.
YN
Return to Service Call Procedures.
Check the connection of each ESS PWB connector. The connectors are correctly connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 9.2)
If the problem persists, replace the Printer PWB (PL 9.2)
If the problem persists, replace the PS DIMM (PL 9.2).
116-381 ABL Initialize RAP
Corrupted data is detected in the ABL (Address Book Library).
Initial Actions
Power Off/On
Procedure
Check the connection of each ESS PWB connector. The connectors are correctly connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Clear the ESS NVM. (Perform this only after explaining to the user the purpose of clearing recipient
information.)
If the problem persists replace the ESS PWB (PL 9.2).
