February, 2008
2-362
WorkCentre 5225, 5230
024-975, 024-976
Launch Version
Status Indicator Raps
024-975 Copy Booklet Sheets Counts Over
Number of sheets detected upon start of printing exceeded maximum number sheets allowed
for Booklet maker.
Initial Actions
Reduce the number of sheets set for Booklet Maker or cancel Booklet Maker job.
Procedure
Cancel job or reduce number of sheets set for this job.
024-976 Finisher Staple Status Failed RAP
• After the Stapler Motor turned On (Forward rotation), the system did not detect that the
Staple Head Home Sensor switched from Off to On within the specified time.
• After the Stapler Motor turned On (Reverse rotation), the Staple Head Home Sensor did
not turn On within the specified time.
Initial Actions
Refer to BSD 12.6.
Procedure
Alternately execute Component Control[012-046 Staple Motor FORWARD ON] and Compo-
nent Control[012-047 Staple Motor REVERSE ON]. The Stapler Motor can be heard.
YN
Check the connections of P/J8819 and P/J8847. P/J8819 and P/J8847 are connected
correctly.
YN
Connect P/J8819 and P/J8847.
Check the wire between J8819 and J8847 for an open circuit or a short circuit (BSD
12.6).
The wire between J8819 and J8847 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Replace the Staple Assembly (PL 22.4). If the problem persists, replace the Finisher PWB
(PL 22.7).
Execute Component Control[012-244 Staple Head Home Sensor]. Alternately execute Com-
ponent Control[012-046 Staple Motor FORWARD ON] and Component Control[012-047 Staple
Motor REVERSE ON].
The display changes.
YN
Check the connections of P/J8818 and P/J8852. P/J8818 and P/J8852 are connected
correctly.
YN
Connect P/J8818 and P/J8852.
Check the wire between J8818 and J8852 for an open circuit or a short circuit (BSD
12.6).
The wire between J8818 and J8852 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Finisher PWB P8852-1 (+) and GND (-) (BSD 12.6).
The voltage is approx. +5VDC.
YN
Replace the Finisher PWB (PL 22.7).
Replace the Staple Assembly (PL 22.4). If the problem persists, replace the Finisher PWB
(PL 22.7).
Replace the Finisher PWB (PL 22.7). If the problem persists, replace the MCU PWB (PL 9.1).
