Xerox WorkCentre 5230 User Manual

February, 2008
2-338
WorkCentre 5225, 5230
024-775, 024-910
Launch Version
Status Indicator Raps
024-775 Output paper for Booklet, over counts 2 RAP
Print Booklet sheets counts over (Not field attachment).
Procedure
Configure the settings to create Booklet for maximum number of pages allowed for the Booklet,
or cancel Booklet settings.
NOTE: If the former is selected, Signature imposition is also carried out per that page number.
024-910 Tray 1 size mismatch RAP
After feeding from Tray 1, the lengths detected by the Registration Sensor and the Tray 1 Size
Switch did not match.
Initial Actions
• Refer to BSD 8.7.
• Reload the tray.
Procedure
Check for foreign substances, distortion and paper powder in the paper transport path. No
distortion, foreign substances, or paper powder are found in the paper transport path.
YN
Clear away the foreign substances and paper powder. Correct the distortion.
Feed paper from another tray. The problem occurs when paper is fed from another tray.
YN
Check the guide. The guide is set correctly.
YN
Set the guide correctly.
Check the operation of the Guide Actuator. The Guide Actuator works.
YN
Set the guide correctly.
Check the installation of the Tray 1 Paper Size Switch. The Tray 1 Paper Size Switch is
installed correctly.
YN
Install the Tray 1 Paper Size Switch (PL 2.1) correctly.
Go to the Tray 1 Paper Size Switch and check the connectors. (BSD 7.1)
Execute Component Control [089-100 Registration Sensor]. Manually activate the actuator of
the Registration Sensor (PL 2.4).
The display changes.
YN
Check the connection of P/J104. PJ104 is connected correctly.
YN
Connect P/J104.
Check the wire between J104 and J403 for an open circuit or a short circuit (BSD 8.7 Flag
1/Flag 2).
The wire between J104 and J403 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P403B-13 (+) and GND (-) (BSD 8.7 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 9.1).
Measure the voltage between the MCU PWB P403B-8 (+) and GND (-) (BSD 8.7 Flag 1).
A
