2-304
WorkCentre 5225, 5230
018-789, 018-790
Launch Version
Status Indicator Raps
018-789 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup set-
tings are indicated. The printer is operational or the Config Report indicates valid network
settings.
YN
Check for damage with the network connection. If there is no damage then there is a problem
with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask the
customer to verify the machine LDAP setups. If OK then there is a problem with the remote LDAP
server.
018-790 LDAP RAP
There is an error in the Lightweight Directory Access Protocol.
Procedure
Verify that print jobs are printing or print a Configuration Report and verify that network setup set-
tings are indicated. The printer is operational or the Config Report indicates valid network
settings.
YN
Check for damage with the network connection. If there is no damage then there is a problem
with the network. Tell the customer that the network requires service.
There is a problem with the LDAP setups on the machine or with the remote LDAP server. Ask the
customer to verify the machine LDAP setups. If OK then there is a problem with the remote LDAP
server.
