February, 2008
2-609
WorkCentre 5225, 5230
116-363, 116-364
Status Indicator Raps
Launch Version
116-363 Print Service Software RAP
An internal shutdown occurred after an SNMP processing error.
Initial Actions
Power Off/On
Procedure
Pull out and insert or replace the DIMM (PL 9.2).
If the problem persists reload Software (ADJ 9.3.1).
If the problem persists, replace the ESS PWB (PL 9.2).
116-364 Timer RAP
A timer failure is detected in the ESS PWB.
Initial Actions
Power Off/On
Procedure
Check the connection of each ESS PWB connector. The connectors are correctly connected.
YN
Connect the connectors.
Turn on the power again. The problem persists.
YN
Return to Service Call Procedures.
Replace the ESS PWB (PL 9.2).
To Next Page
