February, 2008
2-554
WorkCentre 5225, 5230
077-305, 077-307
Launch Version
Status Indicator Raps
077-305 Tray Module Left Hand Cover Interlock Open RAP
BSD-ON:1.4
• The 2TM Cover is open.
• The TTM Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing of the Left Cover of the 2TM or TTM.
Procedure
Check opening/closing of the Left Cover of the 2TM or TTM. The Left Cover of the 2TM or
TTM can be opened/closed.
YN
Reinstall the Left Cover of the 2TM or TTM (PL 12.4/PL 13.7).
Check the installation of the Tray Module Interlock Switch. The Tray Module interlock Switch
is installed correctly.
YN
Install the Tray Module interlock Switch (PL 12.4/PL 13.7) correctly.
Execute Component Control [071-301 Tray Module Left Cover Interlock Switch]. Open and
close the Left Cover of the 2TM or TTM.
The display changes.
YN
Check the connections of P/J554, FS812 and FS813. P/J554, FS812 and FS813 are
connected correctly.
YN
Connect P/J554, FS812 and FS813.
Check the wire between J554-2 and FS812, and between J554-1 and FS813 for an open
circuit or a short circuit (BSD 1.4 Flag 3/Flag 4).
The wires between J554-2 and FS812,
and between J554-1 and FS813 are conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Tray Module Left Cover Interlock Switch (PL 12.4/PL 13.7)
between FS813 and FS812 (BSD 1.4 Flag 3/Flag 4).
The wire between FS813 and
FS812 is connecting successfully when the 2TM Cover or TTM Cover is closed, and
is insulated when the cover is open.
YN
Replace the Tray Module Left Cover Interlock Switch (PL 12.4/PL 13.7).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
Replace the Tray Module PWB (PL 12.6/PL 13.8).
077-307 DUP Cover Open RAP
BSD-ON:1.4
The DUP Cover is open.
Initial Actions
• Power OFF/ON
• Opening/closing of the DUP Cover.
Procedure
Check opening/closing of the DUP Cover. The DUP Cover can be opened/closed.
YN
Reinstall the DUP Cover.
Check the installation of the Duplex Open Switch (PL 8.1). The Duplex Open Switch is
installed correctly.
YN
Install the Duplex Open Switch (PL 8.1) correctly.
Execute Component Control [071-305 Duplex Open Switch]. Open and close the DUP
Cover. The display changes.
YN
Check the connections of P/J124 and P/J541. P/J124 and P/J541 are connected cor-
rectly.
YN
Connect P/J124 and P/J541.
Check the wire between J124 and J541 for an open circuit or a short circuit (BSD 1.4 Flag
5/Flag 6).
The wire between J124 and J541 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Duplex Open Switch (PL 8.1) between J541-4 and J541-5
(BSD 1.4 Flag 5/Flag 6).
The wire between J541-4 and J541-5 is connecting success-
fully when the DUP Cover is closed, and is insulated when the cover is open.
YN
Replace the Duplex Open Switch (PL 8.1).
Replace the MCU PWB (PL 9.1).
Replace the MCU PWB (PL 9.1).
