February, 2008
2-145
WorkCentre 5225, 5230
012-302
Status Indicator Raps
Launch Version
012-302 Finisher Front Cover Open RAP
BSD-ON:12.12
The Finisher Front Cover is open.
Initial Actions
• power OFF/ON
• Opening/closing of the Finisher Front Cover.
Procedure
Check opening/closing of the Finisher Front Cover. The Finisher Front Cover can be
opened/closed.
YN
Reinstall the Finisher Front Cover correctly.
Check the installation of the Front Door Interlock Switch. The Front Door Interlock Switch is
installed correctly.
YN
Install the Front Door Interlock Switch correctly.
Execute Component Control[012-302 Front Door Interlock Switch]. Open/close the Finisher
Front Cover. The display changes.
YN
Check the connections of J8891 and J8982. J8891 and J8982 are connected cor-
rectly.
YN
Connect J8891 and J8982.
Check the wire between J8891 and J8982 for an open circuit or a short circuit (BSD
12.12.
The wire between J8891 and J8982 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Check the conductivity of the Front Door Interlock Switch between J8982-8 and J8982-4
(BSD 12.12).
The wire between J8982-8 and J8982-4 is connecting successfully
when the Front Door Interlock Switch contact is closed, and is insulated when the
contact is opened.
YN
Replace the Front Door Interlock Switch (PL 23.16).
Replace the Finisher PWB (PL 23.16).
Replace the Finisher PWB (PL 23.16). If the problem persists, replace the MCU PWB (PL 9.1).
To Next Page
